Double-glazed Blackart system

Blackart Duo

Intermediate recording application in double-glazed systems providing sound and heat insulation is a system that provides maximum freedom of application out of the ordinary.

Various visual, graphic works, and company logos can be illuminated by LEDs from the background,like a sign in the section or sections determined in the system.

The opaque surfaces to be applied on the partition wall can be used as a fondant-lit whiteboard during our presentation. With this feature, it allows functional and aesthetic applications.

Asymmetrical recordings can be considered as patchwork, stained glass application, glass or wooden panels in different colors and patterns can be used.

This system allows designs that will push the limits of your imagination.

Double-glazed Blackart system

Blackart Duo

Contact us for more information

TECHNICAL SPECIFICATIONS

System Thickness 70 mm
Profile Thickness 1.5, 1.8, 2 mm aluminum
Profile Color Electrostatic painted or anodized
Wick Color Light gray or black
Panel Material 12 mm natural or melamine coating, from the desired color chart
Module Combination Vertical and horizontal (35/100-70 mm aluminum) strut profiles (balance and plumb) are connected to each other with T connection clips. Glasses framed with PVC M-shaped glass wedges are placed between the uprights. The system is completed by attaching the two-sided strut caps to the strut profiles with a click, without screws
Insulation Material Glass wool or rock wool insulation
Glazed Units Construction site assembled unit using 1.5 mm 75 micron electrostatic powder coated or anodized aluminum profiles and 4+4, 5+5, 6+6 mm flat or tempered glass (full glass, half glass, horizontal glass)
Sound Insulation 42 db
Fire Standard F30 (30 min)
Jalousie 25 mm blinds between double-glazing, button operated, in desired color
Wall Finishes With special wall aluminum end profiles
Door Frame Unit Aluminum case monoblock unit
Wing Melamine, laminate, natural veneer and security glass sash
Handle MAB brand or HAFELE WERNER handle, lock, stainless cane handle and similar
Corners 90° or angled special aluminum corner profiles
